4G Mobile Wifi Hotspots Industrial Internet Router / Black Din Rail Wifi Router

Product Categories

Shenzhen Zhibotong Electronics Co., Ltd.

Contact Now

Brand Name : OEM

Model Number : WD123

Certification : CE FCC

Place of Origin : China

MOQ : 1 piece

Price : Negotiate

Payment Terms : T/T, Western Union

Supply Ability : 10000 pieces per month

Delivery Time : 7-30 working days

Packaging Details : Carton box

RAM : 64MB

Flash : 8MB

LAN ports : 4

Keyword : industrial wifi router

Enclosure : Metal

Advantage : with serial ports

Chipset : MT7628AN

Color : Black

Contact Now

4G mobile wifi hotspots industrial wifi router with sim card slot

WD123 adopts MT7628AN chipset, the main frequency up to 580MHZ, designed with large-capacity DDR2 RAM and high-speed SPI Flash, stable performance.

2.4G: 802.11b 19dBm±1dBm,802.11g 17dBm±1dBm,802.11n 17dBm±1dBm

802.11n: -69dBm@10% PER

WD123 \| Hardware Specs
Hardware Specs	MT7628AN/580MHZ Memory:64M , (Max DDR2 256MB) Flash:8M, (Max DDR2 32MB)
Antenna	2 pcs 2.4GHz 5dbi WIFI Antenna ,2pcs LTE Antenna
RF Output Power	11N: 17dBm±1dBm 11G: 17dBm±1dBm 11B: 19dBm±1dBm
Receive sensitivity	11N HT20 MCS7: -72dBm 11N HT40 MCS7: -69dBm 11G 54Mbps: -74dBm 11B 11Mbps: -86dBm
Port Details	4pcs10/100Mbps LAN RJ45 Port； 1pcs10/100Mbps WAN RJ45 Port； 1piece RJ45 CONSOLE system debugging interface 1piece SIM Slot 2pcs relay output interface 1piece RESET butoon 1piece USB2.0 1piece DC Port 1pcs 18PIN terminal (1piece 485,1piece RS232,4piece IO output,2pcs channel IO output , with Latch Function )
Indicator	PWR,WIFI,4G_1,4G_2,4G_3
Power	Recommend 12V 1A power supply
Max Power	<7W
WD123 \| Firmware Specs
Factory Default	IP Address:192.168.1.1 User/password:root/admin
Wan	PPPoE,Dynamic IP,Statics IP
Work Mode	Router
DHCP	DHCP server； Client table； Statics IP ；
Virtual Server	Port transfer and store. DMZ
Firmware	MTK SDK;OPENWRT.
Security	Wireless encryption, support WEP,WPA,WPA2 and other security encryption modes
DDNS VPN	Not support
WEB Theme Switch	Not support
bandwidth control	Not support
static route	support
System log	support
Others
Working Surrounding	Working Temp:-10℃~40℃ Storage Temp:-40℃～70℃ Working Humidity:10%～90%RH Not Freeze Storage Humidity:5%～90%RH Not Freeze

4G Mobile Wifi Hotspots Industrial Internet Router / Black Din Rail Wifi Router
